The Godex EZ1100 Plus barcode desktop thermal printer prints 203dpi labels in either thermal transfer for direct thermal modes at 2 to 4 inches per second. Features includes 4MB flash memory, adjustable reflective sensor which is center aligned and can handle labels on 1", 1.4" or 3" cores. Comes with QLable-IV application software. Optional stripper module (label peeler), label stand, cutter model and ethernet available.
Resolution
203dpi (8 dot/mm)
Print Mode
Thermal Transfer/ Direct Thermal
CPU
32 bit
Memory
4MB Flash, 8MB SDRAM
Print Speed
2 ips- 4 ips
Print Length
Min. 12mm (0.47")
Max 1727mm (68")
Print Width
108mm (4.25")
Sensor Type
Adjustable Reflective sensor; Fixed transmissive, center aligned
Sensor Detection
Type
Label gap and black mark sensing
Detection
Label length auto sensing and/or program command setting
Media
Label Roll OD
Max 125mm (4.92")
Core Diameter
1", 1.5", 3"
Width
25mm (1") to 118mm (4.64")
Thickness
0.06mm to 0.25mm (0.0025" to 0.0098")
Ribbon
Length
300M (981ft)
Max Ribbon Roll OD
68mm (2.67")
Ribbon Width
30mm to 110mm (1.88" to 4.33")
Coating
Outside only
Core Inner Diameter
25.4mm (1")
Printer Language
EZPL (Firmware downloadable)
Software
Application
QLabel-IV (EZPL only)
DLL & Driver
Microsoft Windows NT 4.0, 2000, XP and Vista
Resident Fonts
11 resident alphanumeric fonts (included OCR A & B), those are expandable 8 times horizontally and vertically. All bit mapped fonts in 8 orientations. Scalable font (Code Page 850 & 852) in 4 orientations.
Font Download
Windows bit mapped in 8 orientations. True Type font (ver.2.XX) and Asian fonts in 4 orientations
Image Handling
BMP, PCX, Support ICO, WMF, JPG, EMF file through software
Barcodes
Code 39, Code 93, Code 128 (subset A, B, C), UCC/EAN-128 K-Mart, UCC/EAN-128, UPC A/ E (add on 2 & 5), I 2 of 5, I 2 of 5 with Shipping Bearer Bars, EAN 8/13 (add on 2 & 5), Codabar, Post NET, EAN 128, DUN 14, MaxiCode, HIBC, Plessey, Random Weight, Telepen, FIM, China Postal Code, RPS 128, PDF 417, Datamatrix code & QR code
Interfaces
Serial Port
RS232 (Baud rate: 4800 to 115200, Xon/Xoff, DSR/ DTR)
USB Port
V2.0
Parallel Port
Bi-diretion
Control Panel
Two multiple-color LED lights
Ready, Status
Function Key
FEED
Power
Auto Switching 100/240 VAC, 50/60 Hz
Environment
Operation
40F to 104F (5C to 40C)
Storage
-4F to 122F (-20C to 50C)
Humidity
Operation
30 to 85%, non condensing, Free air
Storage
10 to 90%, non condensing, Free air
Cert. Approval
CE, FCC Class A, CCC, CB, cUL, BSMI
Printer Dimension
Length
285mm (11.2")
Height
171mm (6.8")
Width
226mm (8.9")
Weight
2.72 kg
Options
Rotary Cutter Module
Stripper Module
Compact Flash (CF) Card socket with Real Time Clock (RTC)
Internal Ethernet Adapter Card
Packing
USB cable, power cord, parallel cable, ribbon, ribbon shaft (1" core), empty ribbon core, label, label roll core, CD, Quick Start Guide, cleaning card.
