Mimaki JFX200-2513 EX 98 x 51" UV-LED Flatbed Graphics UV Printer

SKU
JFX200-2513
$66,704 $63,528
Actual stock determine at the time of order confirmation.
Pay as low as per month in 4 equal installments interest free
Pay as low as per month in 4 equal installments interest free
We also accept

Flatbed UV Printer

The Mimaki JFX200-2513EX transforms your shop into a high-value production center by combining true 4′× 8′ UV-LED flatbed printing with speeds up to 200 m²/h in a cost-effective entry model. Its 2.5D Texture Maker and white ink circulation deliver striking textured graphics, while the 60 mm thick-media bed and dual-zone vacuum table adapt to everything from signs to dimensional décor. User-focused front-access controls and RasterLink RIP ensure you hit deadlines with minimal downtime

Features:

  • 4′ × 8′ Print Bed
  • 200 m²/h Draft Mode
  • 2.5D Texture Maker
  • White Ink Circulation
  • 60 mm Media Thickness

PRODUCT OVERVIEW

With a choice of inks, including white and clear, these flatbeds deliver endless options to print to a wide range of substrates. Seamlessly create signage, posters, wayfinding, decorative panels and more.

JFX200-2531:

  • Print single sheets up to 8’ x 10’, dual sheets up to 4’ x 8’ or a variety of pre-cut pieces
  • Dual origin points to increase productivity
  • Two independent vacuum pumps and user-adjustable layout pins
  • Standard ionizer bar reduces static-related print issues
  • Uninterrupted Ink Supply System included
  • Eco-friendly with low VOC, GREENGUARD Gold certified UV-LED inks
  • RIP software RasterLink6 included



Items included with the Mimaki JFX200-2513 EX 4' x 8' UV Flatbed Printer

  • Dual-zoned vacuum table and user-adjustable layout pins
  • Foot pedal to easily control vacuum when loading media
  • Nozzle Recovery System and Nozzle Check Unit
  • Variable Dot Technology and Mimaki Advanced Pass System (MAPS) for smooth gradients and solids
  • Greenguard Gold
  • UV-LED inks in 4 and 6 color configurations plus Clear, Primer and White
  • Updated RasterLink6 Plus to support textured print workflows (2.5D)
  • USB/Ethernet connectivity
More Information
Product Name Mimaki JFX200-2513 EX 98 x 51" UV-LED Flatbed Graphics UV Printer
Certifications VCCI class A, CE mark, CB report, U.S. safety standard UL (UL62368-1), RoHS Directive, FCC Class A, Machinery directive, EAC, RCM
Interface USB2.0
Power Supply 200 V AC-240 V AC, 50 Hz/60 Hz, less than 12 A
Power Consumption AC200V: 2.88 kVA or less
Operating Temperature 59° – 86° F (15-30° C)
Operating Humidity 35–65 % RH (Non condensing)
Printer Type Inkjet
Dimension 173.2″ x 96.4″ x 49.2″ (439.9 x 244.9 x 125 cm)
Weight 650.00 Kg
Manufacturer Mimaki
